HEAVY DUTY FIXED MARINE WINDOW – SERIES 1250

fixed marine window

Marine Window For Use In:

  • Yachts
  • Coastal Cruisers
  • Pilot Houses
  • Jet Boats
  • Salon

The Series 1250 is a clamp ring window designed specifically for the most severe marine applications. It is offered only as a stationary (non-opening) window. It features a choice of 3/8″ or 1/2″ glass.  Frames are available in anodized black, anodized clear, or a selection of powder coat colors.

Installation is quick and easy. You simply push the window into the rough opening and fasten the interior clamp ring to the inside of the window frame for a water-tight exterior and factory finished interior. For boats where this installation type may present problems, we can also eliminate the interior trim ring and drill and countersink holes in the exterior flange for easier exterior fastened installation.

Other marine windows products: Standard Duty Fixed Window – Series 1150, Standard Duty Sliding Window – Series 1200, Top Hinge – Vented Windows – Series 1275Houseboat Elite Windows – Series 1600Houseboat Elite Dual Pane Windows – Series 1800

Specifications:

  • Shapes: Rectangle, Parallelogram, Single Slope, and others
  • Mounting: Trim Ring
  • Wall Thickness: 1/8″ to 2-1/2″
  • Radius: 2-1/2″, 3-0″ or mitered corners available
  • Frame Depth: 1-1/4″
  • Glass: 3/8″ or 1/2″ tempered glass
  • Glass Tint: Clear, Solar Grey (Special Order)
  • Frame: Anodized Clear (Silver), or a selection of powder coat colors.
  • Standard Amenities: Window, trim ring, stainless steel fastners, and flange seal tape

Specification Sheet Printable Version
Installation Guide Printable Version


Glass Tints

Glass-Tints-21

Powdercoat

powdercoat-options


Heavy Duty Fixed Window – Series 1250

Anodized Clear Frame Anodized Clear Frame
Black Powder Coat Frame (Deep Textured Black w/ Matt Finish) Black Powder Coat Frame
White Powder Coat Frame (Smooth Texture w/ Semi-Gloss Finish) White Powder Coat Frame
Light Gray Powder Coat Frame (Smooth Texture w/ Semi-Gloss Finish) Light Gray Powder Coat Frame
Almond Powder Coat Frame (Smooth Texture w/ Semi-Gloss Finish) Almond Powder Coat Frame
Clear Tint Glass Clear
28% Gray Tint Glass 28% Gray
